23. MODIFICATIONS TO THE PROGRAMME
23.1.GENERAL SPECIFICATIONS
The MITSUBISHI PLK B 1006 is equipped with an extremely versatile and easy-to-use software.
To modify a sewing programme, of a pocket embroidery or a label follow the instructions given below, which
will take you, step by step, all the way to saving the programme onto a Floppy Disk or into the Internal
Memory.
With the jigs lowered, press the MODIFY (PROGRAMME MODIFICATION) key.
The red LED above the key lights up enabling this function.
Press the FUNCTION (SELECT FUNCTIONS) key to enable the following FUNCTIONS:
MAIN MENU
1 STITCH Enter this menu to modify the sewing programme
2 SPEED Enter this menu to modify the sewing speed
3 CODE Enter this menu to add or delete codes and signals
4 MOVE (B) Enter this menu to move a selected BLOCK within a programme
(Programmes constructed on the machine)
Choices within this menu:
SUBMENU "1 STITCH"
1 BLOCK Modify the seam between two points selected within a programme
Choices within this menu:
1.BREAK (double line)
2.ARC (circle arc, regular curve)
3.CURVE (irregular curves)
4.LINE (line)
5.ZIG (zigzag)
2 FEED Modify the trial shift
Choices within this menu:
1.START POINT MODIFY (modify start point)
2.FEED BLOCK MODIFY (modify shift path
3 DEL Delete ONE stitch
4 ADD Add ONE stitch
Choices within this menu:
1.ADD 1 STITCH (of the required length)
2.ADD SOME STITCH (same as the previous stitch)
5 MOD Modify the length of a stitch
Choices within this menu:
1.1 ST. DATA FIX (keep the following stitches in the same position)
2.1 ST. DATA MOVE (move the following stitches in the quantity set)
SUBMENU "2 SPEED"
1 ALL Means modifying the sewing speed, from that point in the programme until its end.
2 N. STICHES Means modifying the speed, from that point in the programme, ONLY
for a determined number of stitches.
There are four types of speed:
1 L Low 2 MD2 Medium-Low 3 MD1 Medium-High 4 H High
SUBMENU "3 CODE"
1 DEL. CODE Means CANCELLING codes
2 ADD. CODE Means ADDING codes
Type of codes used in the programmes and their functions: FUN 1: Internal Jig - Backward movement at
end of first seam
1 STITCH
1 BLOCK 2 FEED 3 DEL
4ADD 5MOD
2 SPEED
1 ALL
2 N. STITCHES
1 BREAK 2 ARC 3CURVE
4 LINE 5 ZIG
3 CODE
1 DEL. CODE
2 ADD. CODE
