A-2 Videojet DataFlex 6530 Operator Manual - Rev AA
Inputs/Outputs
External Inputs 3 PNP inputs, configurable from:
Print sensor 1
Print sensor 2
Print sensor select
Inhibit print
External error/stop
Clear print queue
External Outputs 2 relay outputs
(1 change-over + 1 N/O) and 2 PNP +24V outputs
(max source current = 100mA per output),
configurable from CLARiTY Configuration Manager
On-line/Off-line
Warning
Busy
Printing (actually energising print dots)
Labeller feed
Print cycle active (Start to end of print and ribbon
rewind)
Update print queue full
New allocation
Print failed (i.e. interrupted in mid print)
Fault
Operator Interface (CLARiTY) TFT SVGA 800 x 480
Power supply requirements 100 - 240 VAC, 50/60 Hz, 1.56A
Operating Temperature 0° - 40° C (32° - 104° F)
Technical Specification 53 mm
Table A-1: Technical Specifications (continued)
