VIDEOJET DataFlex 6530 - Section 1 Introduction; 1.1 Equipment Description

Videojet DataFlex 6530 Operator Manual - Rev AA
Section 1 Introduction
This chapter contains the following topics:
• Equipment Description
• About this Manual
• Related Publications
• Content Presentation
• Abbreviations and Acronyms
• Chapters in the Manual
1.1 Equipment Description
The main parts of the Videojet DataFlex 6530 printer are described as follows:
• Printer: Houses the printhead and ribbon. The data is transferred to the printhead
from the controller. The printhead prints onto the packaging film.
• CLARiTY Controller Display: Houses the power supply unit and touch screen. You
can access jobs, setup jobs, set the various print parameters using the touch screen.
Figure 1-1: Videojet DataFlex 6530 Printer and CLARiTY Controller Display
1. Interconnecting Cable
2. Printer
3. CLARiTY Controller Display
and Power Supply Unit (PSU)
