VIDEOJET DataFlex 6530 - Appendix A Specifications

Videojet DataFlex 6530 Operator Manual - Rev AA A-1
Appendix A Specifications
Introduction
This section provides the printer specifications and contains the following topics:
• Technical Specifications
• CLARiTY Controller Specifications
• Print Specifications
• Networking and External Communications
• Printer Dimensions
• CLARiTY Controller
A.1 Technical Specifications
Table A-1 lists the technical specifications of the printer.
Technical Specification 53 mm
Printer
Unique Solid State Ribbon Drive Intermittent Motion and Continuous Motion
Printhead 53 mm (2.1”), 300 dpi, 12 dots/mm
Print Area - Intermittent Motion Mode 53 mm (W) x 75 mm (L) (2.1” x 3.0”)
Print Area - Continuous Motion Mode 53 mm (W) x 300 mm (L) (2.1” x 11.8”)
Ribbon Width 20 mm - 55 mm (0.8” - 2.2”)
Maximum Ribbon Length 1200 metres (3937’)
Print Speed
Intermittent Motion Mode 10 mm/sec - 800 mm/sec (0.4”/sec - 31.5”/sec)
Continuous Motion Mode 1 mm/sec - 1000 mm/sec (0.04”/sec - 39.4”/sec)
Maximum Throughput Normal print mode: 500 ppm
High throughput mode: 700 ppm
Note: ppm (prints per min) is dependent on pack size.
Dimensions
Printhead (including cassette) 204 mm (W) x 178 mm (H) x 182 mm (D)
Touch Screen Display 240 mm (W) x 165 mm (H) x 34 mm (D)
Power Supply Unit (PSU) 226.87 mm (W) x 150 mm (H) x 85 mm (D)
Table A-1: Technical Specifications
