A-8 Videojet DataFlex 6530 Operator Manual - Rev AA
A.6 CLARiTY Controller
Figure A-3 shows the dimensions of the CLARiTY controller.
(5.65 inches)
143.5 mm
(9.44 inches)
240 mm
(9.44 inches)
240 mm
(1.33 inches)
34 mm
(3.34 inches)
85 mm
151 mm
(5.94 inches)
(8.89 inches)
226 mm
165 mm
(6.49 inches)
176 mm
(6.92 inches)
Touch Screen Display and PSU Combined
Touch Screen Display
PSU
Figure A-3: CLARiTY Controller Dimensions
