Troubleshooting
8.3 CLARiTY Display Faults
Fault Cause Solution
CLARiTY GUI not
powering up
Low profile connection
between printer and power
supply not properly
connected/seated
Check and correct.
CLARiTY GUI not inserted
onto port on power supply
Check and correct.
Check the 5A fuses on the
power supply near the
power entry module
Replace fuse(s) as necessary.
Faulty power supply Replace as necessary.
Faulty power supply PCB Replace as necessary.
Faulty main printer PCB Replace as necessary.
Power plug not fully
inserted into power entry
module
Check and correct.
Power not turned on at the
source or at the power
supply
Check and correct.
Table 8-3: CLARiTY Display Faults
