Videonics MXPro DV - Specifications

APPENDIX D
TECHNICAL SPECIFICATIONS
MXProDV is a four-input video production switcher, mixer, frame synchro-
nizer/TBC (Time Base Corrector), Manual Color Corrector, and special effects
generator.
Table 20: MXProDV Technical Specifications
GENERAL
Power Supply External in-line; 110VAC@60Hz/220VAC@50 Hz
universal CE/FCC/UL/CSA Approved
(Non-US/Canada versions meet local regulatory standards)
Dimensions 16.6” x 9.5” x 3”
422mm x 241mm x 76mm
Weight 4 lbs. (1.8 kg)
Ambient Temperature 32-104°F
0-40°C
Ambient Humidity Less than 90%
ANALOG INPUTS
Video 4 x S-video (Y/C): Y=1 Vp-p, C=0.30 Vp-p, 75-ohm,
4-pin mini-DIN connectors
4 x composite: 1.0 Vp-p 75-ohm, RCA connectors
Audio 4 x 2 (L and R) RCA connectors, 50 k ohms
GPI Mini-jack
ANALOG OUTPUTS
Video (PREVIEW & MAIN) 1.0 Vp-p, 75 ohm, PREVIEW=1x RCA; MAIN=2x
RCA Connectors and 2x S-Video
(MAIN): Y=1.0 Vp-p, C=0.3 Vp-p; 75 ohm, 4-pin mini-DIN connector
Audio (L and R) 1 k ohms, 2x L+R RCA connectors
Headphone Stereo jack, 8-100 ohms
DIGITAL INPUTS
2 x 4 pin IEEE 1394 (FireWire, i.LINK) connectors, Audio and Video
Effects
