MXPRODV USER GUIDE CHAPTER 3
38
Live Broadcast Configuration
The configuration described in this section is useful in a Live Broadcast environ-
ment. This installation example shows the use of analog equipment only.
1 Connect the VIDEO OUT from Camera 1 to VIDEO IN 1 (Y/C) on the MXProDV rear
panel. Connect the AUDIO OUTs from Camera 1 to AUDIO IN 1 on the rear panel.
2 Connect the VIDEO OUT from Camera 2 to VIDEO IN 2 on the MXProDV rear panel.
Connect the AUDIO OUTs from Camera 2 to AUDIO IN 2 on the rear panel.
3 OPTIONAL – Connect an audio source (CD player, tape deck, or microphone) to
AUDIO IN 4 on the MXProDV rear panel.
4 Connect a Composite-type monitor to the PREVIEW OUT jack on the rear panel.
5 OPTIONAL – Connect a GPI trigger device to the GPI CONTROL on the MXProDV
rear panel.
6 OPTIONAL – Connect a character generator (such as a Videonics TitleMaker or Pow-
erScript) to the OUT Y/C jack on the rear panel.
With this configuration you can superimpose titles from the character generator atop
the output signal.
7 Optional: Connect a recording VCR to the OUT Y/C jack on the rear panel.
If you are using the optional character generator (described above), connect the out-
put from this device to the VCR input.
8 Connect an Output Monitor to the recording VCR so you can see the signal being
recorded.
9 Connect the Power Cord and Transformer to the MXProDV rear panel. See “Power
Connector” on page 31 for instructions.
Use the Route function (see page 92) to make sure your devices are directed to the
correct MXProDV channels.
