Vigilant MX1 - Page 55

Document: LT0344 Vigilant MX1 Operator Manual
Issue 2.4 8 August 2017 Page 5-5
The ZONESF2 option in the Recall menu (see Figure 5-2) allows the
off-normal zones to be recalled.
Fig 5-7 – Recall Zones Menu
Press:
 OFF NMLF1 to show all off-normal zones (i.e., not in a Normal
state)
 ALARMF2 to show all zones in alarm
 FAULTSF3 to show all zones in fault
 DISABLESF4 to show all disabled zones.
If your panel is connected to a network you will see the following menu
after you select one of the menu items:
Fig 5-8 – Recall Zones Network Menu
Press:
 LOCALF1 to show the selected zones on the local MX1
 ALL SIDSF2 to show the selected zones on the network
 ENTR SIDF3 to show the selected zones on a particular MX1
panel. This will prompt you to enter the SID of the panel to search.
The zones are displayed in numerical order, starting with the lowest
numbered zone. An example is shown in Figure 5.9.
Recall zones : xxxxx
|
LOCAL
|
ALL SIDS
|
ENTR SID
Select SIDs to search |
Recall zones
|
OFF NML
|
ALARMS
|
FAULTS
|
DISABLES
Recall
Zones
