Vigilant MX1 Operator Manual Document: LT0344
Page 5-6 8 August 2017 Issue 2.4
Zone 003 Std Detection G1 |
Shop | PREV
| NEXT
Fault | MENU
Fig 5-9 – Off-Normal Zone
The display shows the zone number and its operating profile on the top
line, the zone text on the second line, and the zone status on the third
and fourth lines. Refer to page 1-15 for details on the zone status
conditions.
Function keys NEXTF3 and PREVF2 step forwards and backwards
through the list of zones.
The ALL-PNTSF3 option in the Recall menu (see Figure 5-2) allows
all configured points to be recalled.
If your panel is connected to a network you will see the following menu:
Fig 5-10 – Recall All Points Network Menu
Press:
LOCALF1 to show the selected points on the local MX1
ALL SIDSF2 to show the selected points on the network
ENTR SIDF3 to show the selected points on a particular MX1
panel. This will prompt you to enter the SID of the panel to search.
All configured points will be displayed starting at the lowest numbered
point, irrespective of the point condition. An example is shown in Figure
5-11.
