Volvo L90E - Relays L90 E

Electrical system, specifications L90E L90Eردﻮﻟ قﺮﺑ ﻢﺘﺴﯿﺳ تﺎﺼﺨﺸﻣ
166
L90 E
ردﻮﻟ یﺎﻫ ﻪﻟر
Relays L90E
ﻪﻟر دﺮﮑﻠﻤﻋ ﻪﻟر دﺮﮑﻠﻤﻋ
1 ﺖﮐﺎﺑ ﻦﮐ ﻊﻄﻗ 12 15
EA –
هﺪﻨﻨﮐ ﻪﯾﺬﻐﺗ
2 15
A
هﺪﻨﻨﮐ ﻪﯾﺬﻐﺗ 101 ﮏﯿﺗﺎﻣﻮﺗا یرﺎﮑﺴﯾﺮﮔ ﻢﺘﺴﯿﺳ
3 مﻮﺑ ﻦﮐ ﻊﻄﻗ 202 ترﺎﺘﺳا ندﻮﻤﻧ ﻪﯿﻠﺨﺗ هﺪﻧرادزﺎﺑ
4 15
B
هﺪﻨﻨﮐ ﻪﯾﺬﻐﺗ 601 ﻪﯾﻮﻧﺎﺛ نﺎﻣﺮﻓ ﭗﻤﭘ
5 ﺐﻘﻋ ﻪﺸﯿﺷ بوﺎﻨﺘﻣ ﻦﮐ کﺎﭘ فﺮﺑ 602 (نﺎﻣﺮﻓ رﻮﯿﻟ یوزﺎﺑ هﺎﮔ ﻪﯿﮑﺗ ﻞﺤﻣ رد) نﺎﻣﺮﻓ رﻮﯿﻟ هﺪﻨﻨﮐ لﺎﻌﻓ
6 ﻮﻠﺟ ﻪﺸﯿﺷ بوﺎﻨﺘﻣ ﻦﮐ کﺎﭘ فﺮﺑ 801 عﻮﺒﻄﻣ ﻪﯾﻮﻬﺗ
7
BSS –
مﻮﺑ ﻖﯿﻠﻌﺗ ﻢﺘﺴﯿﺳ 802 عﻮﺒﻄﻣ ﻪﯾﻮﻬﺗ
8 ترﺎﺘﺳا ژﺎﺘﻟو هﺪﻧرادزﺎﺑ 803 یدﺎﺑ ﻖﯿﻠﻌﺗ ، رﻮﺗاﺮﭘا ﯽﻟﺪﻨﺻ
9 ترﺎﺘﺳا هﺪﻧرادزﺎﺑ 2501 ﻦﮑﻣﺮﮔ ﺶﯿﭘ
10 (ﯽﻓﺎﺿا) رﺎﮐ یﺎﻬﻏاﺮﭼ
RF
1 ﺎﻤﻨﻫار نز ﮏﻤﺸﭼ ﻪﻟر
11 (ﻞﻧﺎﭘ ﯽﮑﯿﻧوﺮﺘﮑﻟا لﺮﺘﻨﮐ ﻪﻋﻮﻤﺠﻣ)
I-ECU
ﻪﻠﯿﺳﻮﺑ لﺮﺘﻨﮐ هﺪﻨﻨﮐ ﻪﯾﺬﻐﺗ 30
RT
801 عﻮﺒﻄﻣ ﻪﯾﻮﻬﺗ ﯽﻧﺎﻣز ﻪﻟر
. ﺪﻨﺷﺎﺑ ﯽﻣ ﺲﯾوﺮﺳ یﺎﻬﺘﮐﻮﺳ
IB
و
IA
RE FUNCTION RE FUNCTION
1 Bucket positioner 12 15EA-feed
2 15A-feed 101 Automatic greasing system
3 Boom kick-out 202 Unloading starter inhibitor
4 1 SB-feed 601 Secondary steering pump
5 Intermittent wiper rear 602 Activation of lever steering (positioned in the lever steering arm
rest)
6 Intermittent wiper front 801 Air conditioning
7 Boom Suspension System - BSS 802 Air conditioning
8 Voltage starter inhibitor 803 Operator seat. air suspension
9 Starter inhibitor 2501 Preheating
10 Working lights (extra) RF1 Flasher relay direction indicators
11 30-feed controlled by I-ECU RT801 Time relay air conditioning
IA and IB are service sockets.
