Volvo L90E - Automatic Power Shift (APS II)

Gear shifting هﺪﻧد ﺾﻳﻮﻌﺗ
75
ﻚﻴﺗﺎﻣﻮﺗا شور ﻪﺑ هﺪﻧد ﺾﻳﻮﻌﺗ
(
APS II
)
٤ ﺎـﻳ ٣ هﺪــﻧد رد هﺪﻧد بﺎﺨﺘﻧا مﺮﻫا )
( دراد راﺮﻗ
رﻮﺗاﺮﭘا ﻪﺑ ار نﺎﻜﻣا ﻦﻳا هﺪﻧد ﺾﻳﻮﻌﺗ لوﺪﻣ
،رﺎـﻛ ﻞــﺤﻣ ﻂﻳاﺮﺷ ﻪﺑ ﻪﺟﻮﺗ ﺎﺑ ﺎﺗ ﺪﻫد ﻲﻣ
ﻚﻴﺗﺎـﻣﻮﺗا ﺾـﻳﻮﻌﺗ نﻮـﮔﺎــﻧﻮﮔ يﺎﻫ ﻪﻣﺎﻧﺮﺑ
. ﺪﻨﻛ بﺎﺨﺘﻧا ار هﺪﻧد
APS
ﺖﻴﻌﺿو رد هﺎﮕﺘﺳد ﺎﺑ رﺎﻛ
.ﺪﻴﻫد راﺮﻗ ٤ ﺎﻳ ٣ هﺪﻧد ﺖﻴﻌﺿو رد ار هﺪﻧد بﺎﺨﺘﻧا مﺮﻫا لﺮﺘﻨﻛ

.ﺪﻴﻳﺎﻤﻧ بﺎﺨﺘﻧا مﺮﻫا يور ﺮﺑ ار هﺪﻧد ﻚﻴﺗﺎﻣﻮﺗا ﺾﻳﻮﻌﺗ ﺖﻴﻌﺿو

.ﺪﻴﻳﺎﻤﻧ بﺎﺨﺘﻧا ار ﺐﻘﻋ ﺎﻳ و ﻮﻠﺟ ﻪﺑ ﺖﻛﺮﺣ ﺖﻴﻌﺿو

ﺖـﻛﺮﺣ ﻪﺑ عوﺮﺷ ( ﻲﺋاﺪﺘﺑا هﺪﻧد ) ٢ هﺪﻧد رد هﺎﮕﺘﺳد .ﺪﻴﻫد رﺎﺸﻓ ار زﺎﮔ لاﺪﭘ

رد ﻚﻴﺗﺎـﻣﻮﺗا رﻮـﻄﺑ ﺲﻜﺑﺮﻴـﮔ ،ﺪـﺷﺎﺑ ﺖــﻛﺮﺣ لﺎﺣ رد هﺎﮕﺘﺳد ﻪﭽﻧﺎﻨﭼ .ﺪﻨﻛ ﻲﻣ
.دﺮﻴﮔ ﻲﻣ راﺮﻗ ٣ هﺪﻧد
٢-٣-٤ يﺎــﻫ هﺪﻧد رد ﻮﻠﺟ ﻪﺑ ﺖﻛﺮﺣ مﺎﮕﻨﻫ ﻪﺑ ﻦﻴﮕﻨﺳ و ﻚﺒﺳ هﺪﻧد ﺾﻳﻮﻌﺗ

.دﺮﻴﮔ ﻲﻣ ترﻮﺻ ٢-٣-٤ يﺎﻫ هﺪﻧد رد ﺐﻘﻋ ﻪﺑ ﺖﻛﺮﺣ مﺎﮕﻨﻫ ﻪﺑ و
ﺖـﻛﺮﺣ ﻪـﺑ عوﺮــﺷ ٢ هﺪﻧد ﺎﺑ هﺎﮕﺘﺳد ،دﻮﺸﻴﻣ ضﻮﻋ ﺖﻛﺮﺣ ﺖﻬﺟ ﻪﻜﻴﻣﺎﮕﻤﻫ

.ﺪﻨﻛ ﻲﻣ
رد ” سﻮــﻜﻌﻣ هﺪﻧد دﺮﻜﻠﻤﻋ “ ﺶﺨﺑ ﻪﺑ ، ١ هﺪﻧد رد ﺲﻜﺑﺮﻴﮔ نداد راﺮﻗ ياﺮﺑ

.ﺪﻴﻨﻛ عﻮﺟر ﺪﻌﺑ ﻪﺤﻔﺻ
LIGHT
ﻚﺒﺳ هﺪﻧد
مارآ رود رد هﺪـﻧد ﺾـﻳﻮﻌﺗ ﻪــﻛ ﺖﺳا نآ ﻲﻨﻌﻣ ﻪﺑ ﻚﺒﺳ هﺪﻧد ﺖﻴﻌﺿو ﻦﻴﻟوا

هﺎﮕﺘـﺳد ﻲﻳﺎـﺠﺑﺎﺟ مﺎـﮕﻨﻫ ﻪـﺑ ﹰﺎ ــ ﺤ ﻴ ﺟ ﺮ ﺗ ﺖﻴﻌﺿو ﻦﻳا زا و دﺮﻴﮔ ﻲﻣ ترﻮﺻ رﻮﺗﻮﻣ
.دﻮﺷ ﻲﻣ هدﺎﻔﺘﺳا رﺎﺑ نوﺪﺑ
ﹰﺎﺘﺒــﺴﻧ رود رد هﺪﻧد ﺾﻳﻮﻌﺗ ﻪﻛ ﺖﺳا نآ ﻲﻨﻌﻣ ﻪﺑ ﻚﺒﺳ هﺪﻧد ﺖﻴﻌﺿو ﻦﻴﻣود

مﺎـﮕﻨﻫ ﻪـﺑ ﺖـﻴﻌﺿو ﻦـﻳا زا و دﺮﻴـﮔ ﻲـﻣ ترﻮـﺻ لوا ﺖــﻴﻌﺿو ﻪﺑ ﺖﺒﺴﻧ ﺮﺗﻻﺎﺑ
.دﻮﺷ ﻲﻣ هدﺎﻔﺘﺳا ﻚﺒﺳ يﺎﻫرﺎﺑ ﻲﻳﺎﺠﺑﺎﺟ
ﺖﻴﻌﺿو ﻖﺒﻃ هﺪﻧد ﺾﻳﻮﻌﺗ ،دﻮﺷ ﻲﻣ هداد رﺎﺸﻓ ﺮﺧآ ﻪﺑ ﺎﺗ زﺎﮔ لاﺪﭘ ﻪﻜﻴﻣﺎﮕﻨﻫ

.دﺮﻴﮔ ﻲﻣ ترﻮﺻ
HEAVY
ﻦﻴﮕﻨﺳ هﺪﻧد
رود فﻼــﺘﺧا اﺮﻳز دﻮﺸﻧ هداد رﺎﺸﻓ ﹰﻼ ﻣ ﺎ ﻛ زﺎﮔ لاﺪﭘ ﻪﻛ ﺖﺳا نآ ﺖﻟﺎﺣ ﻦﻳﺮﺘﻬﺑ

دﺎــﻳز رﺎﻴﺴﺑ ،دﺮﻴﮔ ﻲﻣ ترﻮﺻ ﻦﻴﮕﻨﺳ و ﻚﺒﺳ هﺪﻧد ﺾﻳﻮﻌﺗ رود نآ رد ﻪﻛ رﻮﺗﻮﻣ
.دﻮﺷ ﻲﻣ
.ﺪﺑﺎﻳ ﻲﻣ ﺶﻫﺎﻛ رﻮﺗﻮﻣ ياﺪﺻ و ﺖﺧﻮﺳ فﺮﺼﻣ ﻪﻜﻧآ ﻪﺠﻴﺘﻧ

HEAVY
ﻦﻴﮕﻨﺳ هﺪﻧد
هﺪـﻧد ﻪﺑ هﺪﻧد ﺾﻳﻮﻌﺗ ،دوﺮﻧ ﻻﺎﺑ نآ ﺖﻛﺮﺣ نﺎﻣز ﺪﻨﻧﺎﻤﻫ رﻮﺗﻮﻣ رود ﻪﻜﻴﻧﺎﻣز ﺎﺗ

.ﺪﻫد ﻲﻤﻧ خر ﻦﻴﮕﻨﺳ
ﺪﻨﻛ ﺖﻛﺮﺣ ﺎﻫ ﻲﻳﻻﺎﺑﺮﺳ رد هﺎﮕﺘﺳد ﻪﻛ دﺎﺘﻓا ﺪﻫاﻮﺧ قﺎﻔﺗا ﻲﻧﺎﻣز ﺖﻴﻌﺿو ﻦﻳا

.ﺪﺷﺎﺑ دﺎﻳز هﺎﮕﺘﺳد ﻲﺸﺘﻠﻏ ﺖﻣوﺎﻘﻣ ﺎﻳ و
(
manual
)
MAN
ﻲﺘﺳد شور ﻪﺑ هﺪﻧد ﺾﻳﻮﻌﺗ ﺖﻴﻌﺿو
مﺎـﺠﻧا ( ﻲﺘـﺳد ) ﻚﻴﺗﺎـﻣﻮﺗاﺮﻴﻏ رﻮـﻄﺑ هﺪــﻧد ﺾﻳﻮﻌﺗ ،رﻮﺗﻮﻣ نﺪﺷ ﻦﺷور زا ﺲﭘ
.ﺪﻴﻨﻛ عﻮﺟر ٧٤ ﻪﺤﻔﺻ ﻪﺑ .دﻮﺷ ﻲﻣ
Automatic Power Shift
(APS II)
(Gear selector in speed gear
position 3 or 4)
The shift modulation allows the
machine operator to select different
automatic shifting programmes
(modes) depending on the
operating conditions.
Operating in the APS position
• Turn the gear selector control to gear position 3 or 4.
• Set the shift mode selector within the automatic range (not the
manual).
• Select directional gear.
• Accelerate and the machine will start in 2nd gear (basic gear).
If the machine is already moving, it will engage 3rd gear
automatically.
• Up- and downshifts are made between 2nd - 3rd - 4th gears
forward and between 2nd - 3rd - 4th gear in reverse.
• When the direction of travel has been changed the machine will
start off in 2nd gear
• For shifting down to 1st gear. see "Kick-down function" on the
next page.
Position LIGHT
• The first position means that the gear shifting will take place at
low engine speeds and is preferably used for transport operations
without load.
• The second position means that the gear shifting will take place
at a slightly higher engine speed than in the first position and is
used for lighter loading-carrying operations.
• With the accelerator fully depressed, upshifting takes place
according to the HEAVY position.
• The best utilisation is obtained if the accelerator is not depressed
fully, as the difference in engine speed at which up-shifting takes
place between the LIGHT and HEAVY positions will be more
noticeable.
• Results in lower fuel consumption and lower noise level.
Position HEAVY
• The machine does not shift until higher engine and travelling
speeds have been reached.
• Preferably used in cases where the machine changes gear when
operating uphill or when the rolling resistance is great.
Position MAN (manual)
• After starting gear shifting is done manually, see page 74.
ﺾﻳﻮﻌﺗ ﺖﻴﻌﺿو
Mode selector
