Volvo L90E - Material Handling Arm L120 E

Material handling arm L120E L120 E ردﻮﻟ رﺎﺑ ﻞﻤﺣ یوزﺎﺑ
196
L120 E
ردﻮﻟ رﺎﺑ ﻞﻤﺣ یوزﺎﺑ
23/5
R
25 ﺎﻫﺮﯾﺎﺗ
هﺪﺷ ﺐﺼﻧ تﺎﻘﻠﻌﺘﻣ
92008 ﻪﺘﺳد هرﺎﻤﺷ
500
kg
(1103
lb
) نزو
Material handling arm L120E
Tyres 23.5R25
Attachment Bracket-mounted
Order No. 92008
Weight 500 kg (1103 Ib)
1624 mm (5 ft 3.9 in) P 1363 mm (4 ft 5.7 in) J 2853 mm (9 ft 4.3 in) D
5408 mm (17 ft 8.9 in) Q 1907 mm (6 ft 3.1 in) K 2209 mm (7 ft 3.0 in) E
6341 mm (20 ft 9.6 in) R 2452 mm (8 ft 0.5 in) L 1565 mm (5 ft 1.6 in) F
7274 mm (23 ft 10.4 in) S 2023 mm (6 ft 7.6 in) M 3298 mm (10 ft 9.8 in) G
3017 mm (9 ft 10.8 in) N 4432 mm (14 ft 6.5 in) H
4011mm (13 ft 1.9 in) O 5565 mm (18 ft 3.1 in) I
رﺎﺑ ﻞﻤﺣ یوزﺎﺑ یاﺮﺑ رﺎﺑ لوﺪﺟ
Loading table for material handling arm
Mechanical 92008 Arm extension
92008 ﯽﮑﯿﻧﺎﮑﻣ ﯽﻗﺎﺤﻟا یوزﺎﺑ
لدﺎﻌﺗ ﻪﻧزو نوﺪﺑ
Without counterweight
(*
رﺎﺑ ﻪﻠﺻﺎﻓ
Distance to load *)
Arm extention
ﯽﻗﺎﺤﻟا یوزﺎﺑ
3640 kg (8025 lb) 4104 mm (13 ft 5.6 in)Retracted (A)
(A)
ﻦﺘﻓر ﻞﺧاﺪﺑ ﻼﻣﺎﮐ
2830 kg (6239 lb) 5237 mm (17 ft 2.2 in)Halfway extended (B)
(B)
هﺪﺷ زﺎﺑ ﻪﻤﯿﻧ ﺎﺗ
2330 kg (5137 lb) 6370 mm (20 ft 10.8
in)
Fully extended (C)
(C)
هﺪﺷ زﺎﺑ ﻼﻣﺎﮐ
Hydraulically folding 92009
92009 ﯽﮑﯿﻟورﺪﯿﻫ ﺖﮐﺮﺣ
2740 kg (6041 lb) 5382 mm (17 ft 7.9 in) Retracted (A)
(A)
ﻦﺘﻓر ﻞﺧاﺪﺑ ﻼﻣﺎﮐ
2300 kg (5071 lb) 6381 mm (20 ft 11.2
in)
Extended (B)
(B)
هﺪﺷ زﺎﺑ
