WAGNER VU 1 - Description; Design of the VU 1 Reciprocator

17
VERSION 03/2020 ORDER NUMBER DOC2330732
VU 1/VU 2/VU 3
5 DESCRIPTION
5.1 DESIGN OF THE VU 1 RECIPROCATOR
P_01791
1
2
3
4
5
8
7
6
Designation
1 Stand
2 Upper stop
3 Gun mounting carriage
4 Counterweight carriage
5 Drive belt
6 Lower stop
7 Electronic switchbox
8 Motor with gear unit
