WAGNER VU 1 - VU 3 Deflection Unit

80
VERSION 03/2020 ORDER NUMBER DOC2330732
VU 1/VU 2/VU 3
13.7 VU 3 DEFLECTION UNIT
P_04294
4
3
1
4
2
5
Order no. Designation
1 1 2407754 Deection axis
2
1 2407753 Drive belt disc
3
1 2407701 Spare drive belt, VU 3-2000
4
2 2407755 Ball bearing, 6306-2RS1
5 1 2407691 Circlip, D30
Wearing parts
