WAGNER VU 1 - Connecting the Reciprocator

32
VERSION 03/2020 ORDER NUMBER DOC2330732
VU 1/VU 2/VU 3
6.6.4 CONNECTING THE RECIPROCATOR
WARNING
Danger from electric current!
Danger to life and risk of injury.
Before connecting the device, ensure that the external controller is switched o and
the emergency stop button is actuated.
The device may only be commissioned if it complies with the basic requirements of
directive 2006/42/EC after it has been assembled.
The requirements of the relevant paragraphs in particular must be met by the operator:
– 1.1.4 Illumination
– 1.2.4.1 Normal shutdown
– 1.2.4.3 Emergency shutdown
– 1.2.4.4 Assemblies of machinery
– 1.2.5 Selecting the control or operating modes
– 1.2.6 Power supply malfunction
– 1.3.7 Risks from moving parts
– 1.3.8 Selection of protective equipment against risks from moving parts
– 15.6 Fire
– 1.5.16 Lightning
– 1.7.1.2 Warning devices
The reciprocator may only be connected to a controller and commissioning carried out if the
danger zone of the reciprocator is secured through suitable safety measures. One possible
safety measure is a guard (fence). If a safety fence with an entry point (door) is used, the safety
function of the controller must satisfy a minimum safety integrity level of SIL 2 in accordance
with EN 62061 and PLd in accordance with EN ISO 13849-1. If a safety fence without an entry
point is used, the safety function of the controller must satisfy a minimum safety integrity
level of SIL 1 in accordance with EN 62061 and PLc in accordance with EN ISO 13849-1.
A guard is not included in the scope of delivery of the reciprocator. It is the user's responsibility
to provide and install the guard.
