WAGNER VU 1 - Gun Arrangement in Multiple Levels; Gun Arrangement for Short Stroke Applications

41
VERSION 03/2020 ORDER NUMBER DOC2330732
VU 1/VU 2/VU 3
6.11.3 GUN ARRANGEMENT IN MULTIPLE LEVELS
P_04282
Guns horizontal, 2 levels Guns horizontal, 3 levels
– Ideally there should be the same number of guns on the left as on the right
6.11.4 GUN ARRANGEMENT FOR SHORT STROKE APPLICATIONS
P_04283
Guns vertical, on one side Vertical guns, on two sides
– Guns optionally on the right or left side
