WAGNER VU 1 - Accessories; Gun Base Support

65
VERSION 03/2020 ORDER NUMBER DOC2330732
VU 1/VU 2/VU 3
12 ACCESSORIES
12.1 GUN BASE SUPPORT
The following basic items will be required for each reciprocator.
Note:
Gun holders and fastening elements are not included in the base support (see Chapter 12.2).
Order no. Designation Stk
2334258 Gun base support (only VU 1 and VU 2) 2
P_01973
9998890 Flange clamp, V40 2
P_00336
2336261 Counterweight VU 1, 1.1 kg; 2.4 lbs
P_01959
2339412 Counterweight VU 1, 15 kg; 33.07 lbs
2363697 Counterweight VU 2, 0.5 kg; 1.1 lbs
P_02857
2406180 Counterweight VU 3, 2.2 kg; 4.85 lbs
P_04292
9925035 Ribbed lock washer, 6 x 10 x 0.7 8
9906036 Hexagon socket head cap screw, M6 x 55 8
9900235 Hexagon socket head cap screw, M6 x 16 16
9921502 Spring washer, A6.0 16
