55
VERSION 03/2020 ORDER NUMBER DOC2330732
VU 1/VU 2/VU 3
8.4 CHECKING AND ADJUSTING THE BELT TENSION MEASURING DEVICE
WARNING
Unauthorized commissioning!
Risk of injury and damage to the device.
The cover has to be removed during setup work.
Ensure that the system cannot be accidentally turned on without authorization!
Note:
The following instructions on belt tension apply to all device heights.
Belt tension should be checked every 6 months.
F
1
2
P_04277
3
4
Designation
3 Deection
4 Free belt length
