VU 1/VU 2/VU 3
5.7 DATA
5.7.1 TECHNICAL DATA
VU 1-1800 VU 1-2400 VU 1-3000 VU 2-1800 VU 2-2400 VU 3-2000
Minimum stroke 100 mm; 3.94 inch
Maximum stroke 1800 mm; 2400 mm; 3000 mm; 1800 mm; 2400 mm; 2000 mm;
70.87 inch 94.49 inch 118.11 inch 70.87 inch 94.49 inch 78.74 inch
Minimal lifting speed V 6 m/min
Maximum lifting speed V 30 m/min
Maximal load on
attachment bracket
(spaced 1 meter from the
lifting slide)
79 kg; 174.17 lbs 33 kg; 72.75 lbs 160 kg;
352.74 lbs
(spaced 2 meter from the
lifting slide)
17 kg; 37.48 lbs
(spaced 3 meter from the
lifting slide)
11 kg; 24.25 lbs
Maximal counterweight
mass
66 kg; 145.50 lbs 31.5 kg; 69.44 lbs 145 kg;
319.67 lbs
Maximal number of guns¹
(PEA-C4XL)
horizontal 8 6 --
vertical 7 7 --
horizontal/vertical 12 7 24
Maximum number of
Z-axis/guns
PEA-C4XL 1.4 4 -- 9
PEA-C4XL 1.8 3 -- 7
Usable stroke of the
linear axis for the gun
PEA-C4XL 1.4 800 mm; 31.49 inch -- 800 mm
PEA-C4XL 1.8 1100 mm; 43.30 inch -- 1100 mm
Rated power, drive motor 0.75 kW 0.55 kW 2.2 kW
Electrical connection 1/P/N/PE AC 230/240 V 50/60 Hz 3 PH 400V
50/60 Hz
IP Code IP 54
Energy eciency class IE 1
Noise emission < 70 dB (A)
Weight 266 kg; 268 kg; 280 kg; 179 kg; 193 kg; 450 kg;
586 lbs 590 lbs 617 lbs 395 lbs 425 lbs 992.08 lbs
1.) In order to function properly, the distance between the guns must be at least 300 mm.
