WAGNER VU 1 - VU 2 Gun Arrangement; Long Stroke Gun Arrangement for 2-4 Guns; Long Stroke Gun Arrangement for 5-6 Guns

42
VERSION 03/2020 ORDER NUMBER DOC2330732
VU 1/VU 2/VU 3
6.12 VU 2 GUN ARRANGEMENT
6.12.1 LONG STROKE GUN ARRANGEMENT FOR 24 GUNS
P_04280
2-4 guns
6.12.2 LONG STROKE GUN ARRANGEMENT FOR 56 GUNS
P_04284
5-6 horizontal guns, 2 levels
– The maximum number of guns depends upon the maximum load and acceptable
exing of the support
– No more than 6 guns
