WAGNER VU 1 - Correct Number of Counterweights; VU 1 Reciprocator

35
VERSION 03/2020 ORDER NUMBER DOC2330732
VU 1/VU 2/VU 3
6.8 CORRECT NUMBER OF COUNTERWEIGHTS
6.8.1 VU 1 RECIPROCATOR
Total load*
[kg]
Number of
counterweights
to be installed
Total load*
[kg]
Number of
counterweights
to be installed
Total load*
[kg]
Number of
counterweights
to be installed
1.1 kg** 15 kg 1.1 kg** 15 kg 1.1 kg** 15 kg
14 0 0 38 22 0 Maximum stroke is reduced by
100 mm
15 1 0 39 23 0 61 16 2
16 2 0 40 24 0 62 17 2
17 3 0 41 25 0 63 18 2
18 4 0 42 26 0 64 19 2
19 5 0 43 27 0 65 20 2
20 6 0 44 28 0 66 20 2
21 7 0 45 29 0 67 21 2
22 8 0 46 16 1 68 22 2
23 9 0 47 17 1 69 23 2
24 10 0 48 18 1 70 24 2
25 10 0 49 19 1 71 25 2
26 11 0 50 20 1 72 26 2
27 12 0 51 20 1 73 27 2
28 13 0 52 21 1 74 28 2
29 14 0 53 22 1 75 29 2
30 15 0 54 23 1 76 30 2
31 16 0 55 24 1 77 30 2
32 17 0 56 25 1 78 31 2
33 18 0 57 26 1 79 32 2
34 19 0 58 27 1
35 20 0 59 28 1
36 20 0 60 29 1
37 21 0
* Including tensile load from hose/cable
** 6 counterweights (at 1.1 kg) are already mounted in the delivery state. If necessary, remove them.
