WAGNER VU 1 - VU 2 Reciprocator; VU 3 Reciprocator

36
VERSION 03/2020 ORDER NUMBER DOC2330732
VU 1/VU 2/VU 3
6.8.2 VU 2 RECIPROCATOR
Total load*
[kg]
Number of
counterweights
to be installed
Total load*
[kg]
Number of
counterweights
to be installed
Total load*
[kg]
Number of
counterweights
to be installed
0.5 kg** 0.5 kg** 0.5 kg**
4 1 14 21 24 41
5 3 15 23 25 43
6 5 16 25 26 45
7 7 17 27 27 47
8 9 18 29 28 49
9 11 19 31 29 51
10 13 20 33 30 53
11 15 21 35 31 55
12 17 22 37 32 57
13 19 23 39 33 59
* Including tensile load from hose/cable
** 23 counterweights are already mounted in delivery state. If necessary, remove them.
6.8.3 VU 3 RECIPROCATOR
Total load*
[kg]
Number of
counterweights
to be installed
Total load*
[kg]
Number of
counterweights
to be installed
Total load*
[kg]
Number of
counterweights
to be installed
2.2 kg** 2.2 kg** 2.2 kg**
20 0 67 22 114 43
21 1 68 22 115 44
22 1 69 23 116 44
23 2 70 23 117 45
24 2 71 24 118 45
25 3 72 24 119 45
26 3 73 25 120 46
27 4 74 25 121 46
28 4 75 25 122 47
29 5 76 26 123 47
30 5 77 26 124 48
31 5 78 27 125 48
32 6 79 27 126 49
33 6 80 28 127 49
34 7 81 28 128 50
35 7 82 29 129 50
36 8 83 29 130 50
37 8 84 30 131 51
38 9 85 30 132 51
39 9 86 30 133 52
40 10 87 31 134 52
41 10 88 31 135 53
42 10 89 32 136 53
