VERSION 03/2020 ORDER NUMBER DOC2330732
VU 1/VU 2/VU 3
6.4 TRANSPORTATION
WARNING
Parts have high weights and centers of gravity!
Risk of injury and damage to the device.
Only use appropriate lifting tackle (fork lift) for assembly.
The reciprocator should not be lifted by the moving parts or the geared motor.
Secure the parts against tipping during transport.
Cordon o assembly area to keep out unauthorized persons.
P_01792
Procedure:
1. Attach a cable or hook to the eyelet.
Secure the cable against slippage.
2. Lift the reciprocator and transport it to its destination.
To Next Page
