20
VERSION 03/2020 ORDER NUMBER DOC2330732
VU 1/VU 2/VU 3
5.4 MODE OF OPERATION
The device carrier on lifting unit 3 is moved up and down by drive belt 5 and the motor
with gear unit 8.
Lifting speed, reversal point or position are all controlled by the central control unit.
Position control is carried out by frequency converter and path measurement via incremental
position encoder.
5.5 VARIANTS
Order no. Designation
2327615 Reciprocator, VU 1-1800 (height of stroke 1800 mm; 70.87 inches)
2327616 Reciprocator, VU 1-2400 (height of stroke 2400 mm; 94.49 inches)
2327617 Reciprocator, VU 1-3000 (height of stroke 3000 mm; 118.11 inches)
2363696 Reciprocator, VU 2-1800 (height of stroke 1800 mm; 70.87 inches)
2363695 Reciprocator, VU 2-2400 (height of stroke 2400 mm; 94.49 inches)
2411131 Reciprocator, VU 3-2000 (height of stroke 2000 mm; 78.74 inches)
5.6 SCOPE OF DELIVERY
Order no. Designation
1
see Chapter 5.5 VU 1/VU 2/VU 3 reciprocator
The standard equipment includes:
1
see Chapter 14 Declaration of incorporation
1 2330731 Operating and assembly manual, German
1
see Chapter 1.3 Operating and assembly manual in the local language
