WAGNER VU 1 - VU 3 Guide Unit

86
VERSION 03/2020 ORDER NUMBER DOC2330732
VU 1/VU 2/VU 3
13.10 VU 3 GUIDE UNIT
2
9
1
P_04295
4
7
Order no. Designation
1 2 2407695 Guide rail, VU 3 (L=2800)
2
4 2407693 Roller cage guide
4 1 2407697 Drive belt distance piece
7 2 2407692 Clamping plate for drive belt
9 8 2407699 Perforated rail
Wearing parts
