WAGNER VU 1 - Page 73

73
VERSION 03/2020 ORDER NUMBER DOC2330732
VU 1/VU 2/VU 3
Order no. Designation
1 1 2328948 Motor
2 1 2330653 Counter bracket, d25
3 1 2328950 Gear unit
4
1 2328956 Drive wheel
5 1 2335356 Gear shaft
6
1 2334719 Spare drive belt, VU 1-1800
6
1 2334723 Spare drive belt, VU 1-2400
6
1 2334724 Spare drive belt, VU 1-3000
9 1 2328947 Rotary encoder, Kübler, 5020 VU 1/HU 1
11 1 2335358 Y ange bearing
Wearing parts
