Waters SYNAPT G2 - 1 System Overview

1-1
1 System Overview
This chapter describes the instrument, including its controls, sources, and
IntelliStart™ Fluidics system.
Contents
Topic Page
Waters SYNAPT G2 MS 1-2
SYNAPT G2 MS UPLC/MS/MS systems 1-2
Software 1-3
Instrument sources 1-5
IntelliStart Fluidics system 1-9
Ion optics 1-12
Analyzers 1-13
Mass spectrometer configuration 1-17
Leak sensors 1-18
Vacuum system 1-18
Controls on the instrument’s rear panel 1-19
