Deploying the sprayer platform adjuster assembly 4-5
Deploying the sprayer platform adjuster assembly
To move the sprayer platform out of the source
1. Confirm that the sprayer’s safety cover is installed (see the figure on
page 4-2).
2. Unscrew the thumbscrew on the front of the sprayer platform.
3. Pull out the side thumbscrew and withdraw the sprayer platform from
the source.
4. Release the side thumbscrew, locking the platform in the withdrawn
position.
NanoLockSpray source configuration
Sprayer type Used for
Universal NanoFlow nebulizer
sprayer
Flow injection or for coupling to
nanoACQUITY UPLC with regulated
flow rates down to 100 nL/min.
Borosilicate glass capillary
NanoFlow (see page 4-8).
Extremely low flow rates (less than
100 nL/min).
NanoFlow capillary electrophoresis
(CE) sprayer. For details, see the
Capillary Electrophoresis/Capillary
Electrochromatography Sprayer
User's Guide (part number 6666522).
Stable electrospray by means of a
make-up liquid at the CE capillary
tip. The make-up flow rate is less
than 1 µL/min.
Warning: To avoid electrical shock, ensure the safety cover is in place
over the sprayer.
