B-1
B External Connections
This appendix describes the mass spectrometer’s external connections.
Warning: The mass spectrometer is heavy. To avoid injury, use
suitable machinery and the supplied harness to lift it.
Caution:
• Contact Waters Technical Service before moving the
instrument.
• If you must transport the mass spectrometer, or remove it from
service, contact Waters Technical Service for recommended
cleaning, flushing, and packaging procedures.
See “Troubleshooting using Connections Insight” on page 5-5.
Contents
Topic Page
Mass spectrometer external wiring and vacuum connections B-2
Connecting the Edwards oil-free roughing pump B-3
Connecting to the nitrogen gas supply B-7
Connecting to the collision cell gas supply B-9
Connecting the nitrogen exhaust line B-10
Connecting the liquid waste line B-13
Input/output signal connectors B-15
Connecting the workstation (system without ACQUITY UPLC) B-21
Connecting Ethernet cables (system with ACQUITY UPLC) B-21
Connecting to the electricity source B-22
Connecting the NanoLockSpray source camera B-23
