Installing and removing the corona pin 5-13
Corona pin mounting contact
4. Fit the corona pin to the corona pin mounting contact.
Requirement: Ensure that the corona pin is securely mounted and that
its tip aligns with the sample cone orifice.
Corona pin
TP03130
Corona pin mounting
contact blanking plug
TP03130
Corona pin
Sample cone orifice
