1. Select the preset ID.
2. Click Goto to invoke preset, the camera rotate the preset position.
Or click Home to rotate the camera to the first preset position.
: Channel button. Click or to select the P.T.Z control channel.
: Click or to enter the preset setting page.
: direction button. Click this button to rotate the position of camera..
: Click or to set the camera speed.
: Click or to zoom the lens in or out.
: Click or to adjust the focal length.
: Click or to adjust the aperture.
4.1.2 UTC
The UTC control and function settings are applicable to front-end HD camera and OSD
operation of front-end HD camera.
Click UTC in PTZ control page, the UTC screen is displayed, as shown in Figure 4-8.
Figure 4-8 UTC screen
For HD camera of Motorized lens, click or of zoom, focus and iris to
adjust the view angle and focal length.
For details of OSD operation, see Camera OSD Operation Guide.
