WEG CFW08 Vector inverter Plus - Page 86

85
DETAILED PARAMETER DESCRIPTION
Range
[Factory Setting]
Parameter Unit Description / Notes
P220
0
1
2
3
4
5
6
Local/Remote Selection
Always Local mode
Always Remote mode
Key of the keypad (HMI-CFW08-P
or HMI-CFW08-RP)
Key of the keypad (HMI-CFW08-P
or HMI-CFW08-RP)
DI2...DI4
Key of the keypad (HMI-CFW08-RS)
or serial interface
Key of the keypad (HMI-CFW08-RS)
or serial interface
Default Mode (*)
-
-
Local
Remote
-
Local
Remote
Note: (*) When inverter is powered up (initialization).
In the factory default setting, the inverter is started in local mode
and the key of the HMI-CFW08-P keypad will select the
local/remote mode.
The inverters with dummy panel (without HMI-CFW08-P keypad)
are factory supplied with P220=3.
For more details, refer to item 6.2.6.
P221
(1)
0...8
Local Reference [ 0 - Teclas ]
Selection -
P222
(1)
0...8
Remote Reference [ 1 - AI1 ]
Selection -
Defines the frequency reference selection in the Local and Remote mode.
P221/P222
0
1
2 or 3
4
5
6
7
8
Reference Source
Keys and of the HMIs (P121)
Analog input AI1' (P234, P235 e P236)
Analog input AI2' (P238, P239 e P240)
Electronic potentiometer (EP)
Serial
Multispeed (P124...P131)
Sum of the Analog Inputs (AI1'+AI2') 0 (negative
values are zeroed).
Sum of the Analog Inputs (AI1'+AI2')
≥
(1)
This parameter can be changed only with the inverter disabled (motor stopped).
P220
(1)
0...6
Local/Remote [ 2 - Key
Source Selection HMI-CFW08-P ]
-
Defines the source of the Local/Remote selection.
The description AI1’ as apposed to AI1 refers to the analog signal
after scaling and/or gain calculations have been applied to it.
For factory default setting, the local reference is via the and
keys of the keypad and the remote reference is via analog
input AI1.
The reference value set by the and keys is contained
in parameter P121.
For details of the Electronic Potentiometer (EP) operation, refer to
Figure 6.19.
When option 4 (EP) is selected, set P265 and P266 to 5.
When option 6 (multispeed) is selected, set P264 and/or P265
and/or P266 to 7.
For more details, refer to items 6.2.4 and 6.2.6.
