Operation
Working with attachments 7.12
157
[en] | 05/2019 | 1000408123 | 4080T Basic Line | Operator’s Manual
Fig.155: Loading with the fork-and-
grab attachment
Working with the fork-and-grab attachment
1. Open the attachment.
2. Lower attachment.
3. Set the attachment parallel to the ground.
4. Drive into the material to be loaded.
ð Pay attention to the travel speed.
5. Slightly raise the loader unit.
ð A load is applied to the front axle of the vehicle.
ð The wheel slip can be reduced manually by inching.
6. Close the attachment.
For solid materials, such as solidified manure in stables, the load can be
loosened by tilting in the attachment.
1. Travel to the unloading position in a straight line.
2. Lift the attachment to the required height just before the unloading
position.
3. Drive forward as far as necessary.
4. Empty attachment.
5. Open the attachment.
ð The material falls out.
7.12.9
Using the pallet fork
WARNING
Accident hazard due to pallet fork tines!
The fork tines of the pallet fork can cause serious injury or death during
operation.
► Remove the pallet fork before driving on public roads and transport it
separately.
► In the case of a pallet fork with folding forks, fold them up before driv-
ing on public roads.
► Bent, torn or otherwise damaged forks must not be used.
► Before starting work, ensure that the fork tines on the fork carriage
are safely locked.
► Lower the pallet fork to the ground before leaving the vehicle.
Practice using the pallet forks before working with them for the first time.
