Commissioning
6.4 Warning lights and control lights
94
Operator’s Manual | 4080T Basic Line | 1000408123 | 05/2019 | [en]
“High beam” control light
Illuminates when the high beams are switched on or when
flashing the headlights.
• Vehicle lights on page [}117]
6.4.2
Stability indicator
Fig.74: Location of stability indicator
Vehicles with a telescoping loader unit are equipped with a stability indic-
ator.
The stability indicator is located on the right side of the windshield on the
pillar in the cab.
Fig.75: Display of stability indicator
The display of the stability indicator shows the steadiness of the vehicle
in relation to the lifted load.
The stability indicator warns only in case of insufficient steadiness in a
longitudinal direction and to the front. Lateral loads are not shown by the
stability indicator. For more information: see Stability indicator on page
127.
1 Warning lights (green, orange, red)
2 Ready light (green)
3 “SYSTEM CHECK” button
Green There is a slight risk of the vehicle tipping over.
Yellow There is an increased risk of the vehicle tipping over.
Red There is an acute risk of the vehicle tipping over.
