Fig 8-8 Axial vibration damper
4 Attach the two eye bolts (006, Figure 8-9) to the top cylinder half.
5 Attach the chain (005) to the eye bolts (006).
6 Attach the two shackles (001) to the platform.
7 Attach the two slings (002) to the shackles (001) and the link (003).
8 Attach the spur-geard chain block (004) to the chain (005) and the link (003).
9 Operate the chain block (004) to carefully lift the top cylinder half (007).
10 Attach the engine room crane (008) to the chain (005).
11 Operate the engine room crane (008) to hold the weight of the top cylinder half (007).
12 Remove the chain block (004) from the chain (005).
13 Operate the engine room crane (008) to lower the top cylinder half (007) on to an
applicable surface.
X72DF
AA00-3140-00AAA-530A-A
Maintenance Manual Axial vibration damper - disassemble
Winterthur Gas & Diesel Ltd.
- 364 - Issue 002 2020-10
