PROCEDURE
1 For the maintenance of the turning gear (001, Figure 8-14), refer to the manufacturer’s
instructions.
2 Examine the items that follow:
•
Condition of the tooth flanks of the gear wheels
•
Lubrication of the pinion (002)
•
Lubrication of the flywheel (003).
Fig 8-14 Turning gear and gear wheels
3 If the tooth flanks have a minimum of lubricant remaining or are dry, continue the
procedure.
4 If you use Klüberfluid as lubricant, prepare the lubricant as follows:
4.1 Put an applicable quantity of Klüberfluid into a container.
4.2 Put the container into warm water until the Klüberfluid is at approximately 35°C.
5 Apply a thin layer of lubricant to the teeth (001) of the flywheel and of the pinion as
shown in Figure 8-15.
X72DF
AA00-3206-00AAA-240A-A
Maintenance Manual Turning gear - lubricate the teeth
Winterthur Gas & Diesel Ltd.
- 375 - Issue 002 2020-10
