1.8.4 Numbering of items
WinGD uses the definitions for the numbering of items as follows (refer to Figure 1-4):
•
In axial direction the numbering starts from the flywheel.
•
In radial direction the numbering starts from the center of the flywheel.
Fig 1-4 Engine numbering (generic)
FEDE
n
n
004
003
001
002
n-1
n-1
4
3
2
1
2
1
Legend
FE Free end DE Driving end
001 Cylinder number 003 Thrust bearing
002 Main bearing number 004 Flywheel
X72DF
AA00-0000-00AAA-018L-A
Maintenance Manual About the engine
Winterthur Gas & Diesel Ltd.
- 40 - Issue 002 2020-10
