WinGD X72DF - Direct Controlled Injection Valve - Do a Functional Test

7.6.2 Direct controlled injection valve - do a functional test
Periodicity
Description
Working hours 5000
Duration for performing preliminary requirements 0.0 man-hours
Duration for performing the procedure 0.5 man-hours
Duration for performing the requirements after job completion 0.0 man-hours
Personnel
Description Specialization QTY
Engine crew Intermediate 1
Support equipment
Description Part No. CSN QTY
Injector test bench 94272 1
Valve holder 94273 1
HP hose 94272E 1
Brass wire brush N/A 1
Supplies
Description QTY
Test fluid, ISO 4113 A/R
Spare Parts
Description Part No. CSN QTY
None
SAFETY PRECAUTIONS
WARNING
Injury Hazard. Do not put your fingers near the holes in the nozzle tip. High-pressure fluid
can go through your skin and cause dangerous injury.
WARNING
Health Hazard. Test fluid is harmful to your health.
NOTE: It is not recommended that diesel oil is used as test fluid. Diesel oil can cause
corrosion of the injection valve.
PRELIMINARY OPERATIONS
• The injection valve must be removed from the cylinder cover, refer to section 7.6.1 Direct
controlled injection valve - remove
X72DF
AA00-2722-00AAA-340A-A
Maintenance Manual Direct controlled injection valve - do a functional test
