T-ABDECKUNG KÜ-T1 RT R8 RAL 7035
(5040517)
Cover strip T-KÜ-T1 RT R8 (separate), serves
to cover the profile hole on the frame side,
when using the frame part T-KÜ-T1 RT
KABEL 0,6M RNT
Cover Strip
Adapter for cable transition T-HT KABELÜBERGANGADAPTER H4 M1210
(2126951)
Cable transition adapter for cable transition
T-HT KÜ M1188, e.g. for timber doors, to
cover the fitting contour
T-LB ENDKAPPE STK/RNT HOLZ H4 R12 SW
(5035742)
End cap for frame power supply and tappet
contact (frame side) and keep magnetic clip
7.5 mm with radius 12 mm, e.g. for wooden
entrance doors with 4 mm airgap, in
packages of 10 pieces in a plastic bag
End cap STK/RNT
T-SET 10 X SCHRAUBABDECKUNG
RNT+STK 4MM SW (5044566)
Magnetic clip can be used to optionally
cover the screw holes on the frame power
supply unit, tappet contact and striking
plate (with central screw connection).
Screw cover
