Woodward GCP-30 Series Configuration

Manual 37278B GCP-30 Series - Genset Control
Page 122/174 © Woodward
Engine Delayed Monitoring Of The Analog Inputs
Parameter 279
Ana.in 12345678
SV.del. NNNNNJNN
Analog inputs; engine delayed monitoring Y/N
The analog inputs may be disabled until the engine has reached rated speed ("firing
speed reached"). This parameter specifies which analog inputs are to be constantly
enabled and temporarily disabled by configuring a "Y" or an "N" below the input
number.
Y ................... Once the firing speed has been reached monitoring of the analog in-
put is enabled (the green LED "Protection" illuminates).
N ................... The analog input is monitored always.
Note: Above screen (8 inputs) appears if at least 5 analog inputs are equipped. If
less than 5 inputs are equipped, a screen with 4 inputs appears. If less inputs are
equipped than inputs appear in the screen, only the entries for the equipped inputs
are valid.
Analog Inputs Selectable as Control Inputs
Parameter 280
Ana.in 12345678
control NNNNNNNN
Analog input as control input J/N
This parameter defines for each analog input whether it operates as control input or
not.
J .................... The analog input operates as control input: The analog value is dis-
played and the configured relays are energized when reaching the
configured limits. However, no alarm is issued. No guidance bus
output is performed as well.
(This setting has no effect on the behavior in case a wire breaks)
N ................... The analog input operates as described for the above settings.
Note: Above screen (8 inputs) appears if at least 5 analog inputs are equipped. If
less than 5 inputs are equipped, a screen with 4 inputs appears. If less inputs are
equipped than inputs appear in the screen, only the entries for the equipped inputs
are valid.
