Woodward GCP-30 Series Configuration

Manual 37278B GCP-30 Series - Genset Control
© Woodward Page 55/174
Mains parallel operation (mains interchange (import/export) real power control with one generator)
General
Case 1: Start of the engine
If [P
NT.Setpoint
- P
NT.actual
> P
start
] the engine starts. (a)
Case 2: Stop of the engine
If [P
NT.setpoint
- P
NT.actual
+ P
GN.actual.tot
< P
start
- P
Hyst
] the engine stops. (b)
Example
The power supplied by the mains, which is to be adjusted, is 50 kW. This value is entered into the set point value
screen (see chapter "Controller") as "I0050kW". The generator should be operated with at least 30 kW.
P
NT.setpoint
= -50 kW Incoming/import power has to be entered negative, output/export power positive.
P
star
= 30 kW The minimum power requested by the generator.
P
Hyst
= 10 kW The power hysteresis for stopping.
When inserted into the above-mentioned formula, this means:
Case 1:
The engine starts with the following import mains power: If formula (a) is inverted, this results in
[P
NT.actual
< P
NT.setpoint
- P
start
] ⇒ P
NT.actual
< - 50 kW - 30 kW = -80 kW ⇒ "I0080 kW"
The power supplied by the mains must be at least 80 kW in order for the engine to start. This is then oper-
ated with a minimum power of 30 kW.
Case 2:
The engine stops if it has to supply less than the minimum power minus hysteresis. This is the case with
the following generator power: If formula (b) is inverted, this results in
[P
GN.actual
= stop power engine < - P
NT.setpoint
+ P
NT.actual
+ P
start
- P
hyst
].
[P
GN.actual
< - 50 kW + 50 kW + 30 kW - 10 kW = 20 kW.
If the generator falls below its minimum power minus hysteresis, the engine is stopped. The power im-
ported from the mains therefore remains at the value that is to be controlled until just prior to stopping.
Following stopping, the power supplied by the mains increases to 70 kW.
