WORKSWELL WIRIS PRO - S.BUS through Amimon Connex

8. DIGITAL INPUTS
Note: The simplest way of ensuring reliable receiver funconality is to use a receiver with plain PWM
servo outputs and using an OEM PWM‐S.BUS, oered for purchase as an accessory.
Figure 8.2: OEM PWM converter
In theory, any S.BUS compable receiver might be compable, but due to slight variaons in the implementaon,
not every one reliably is.
Tested S.BUS funconal receivers are:
FUTABA SBE‐1
HITEC OPTIMA D
FUTABA R2008SB
FUTABA R7014SB
Figure 8.3: FUTABA SBE‐1
Figure 8.4: Example of connecng SBUS to OPTIMA D receiver.
