Xerox Phaser 3160B Service Manual

9-16 Phaser 3140/3155/3160 Printer Service Manual
Parts List
Parts List 6.0 Frame
ID No. Name/Description Part Number
1. Control Panel 140N63412
2. Frame-Holder_LSU_L —
3. Frame-Holder_LSU_R —
4. Fan 127N07583
7. Screw-Taptype —
8. Screw-Taptype —
9. Screw-Taptype —
10. Washer-Plain —
11. Ring-CS —
12. Spring-Etc —
18. Pick Up Solenoid 121N01168
19. Manual Solenoid 121N01162
20. Spring-CS —
22. Bush-M-Feed Idle —
23. Shaft-P-Core —
24. Bush-M-Pick Up R —
25. Bush-M-TR L —
26. Guide-M-TR Rib —
27. Feed Bracket —
28.. Plate-P-Saw —
29. Guide-P-TR —
30. Foot-ML80 —
31. Housing-Terminal —
32. Frame-Base —
33.. Bush-TR_L —
34. Spring ETC-Guide Deve —
35. Spring ETC-TR —
36.
36-1.
36.2.
Frame-Left Stopper Pick Up
Spring-TS
Cam-M-Pick Up
—
—
—
37. Gear-Feed 2 —
38. Gear-Idle 23 —
39. Shaft-Feed —
40. Roller-Registration —
41. Shaft-Idle Feed —
