Xerox Phaser 3160B Service Manual

Phaser 3140/3155/3160 Printer Service Manual 9-17
Parts List
42. Roller-Feed 022N02421
43. Frame-Roller Exit Face Down —
44. Stopper-Lever_DR —
45. IPR-P-Ground_Drive —
46. Ground-Fuser —
47. IPR-P-Ground_TR —
48. Terminal-Con —
49. Terminal-Supply —
50. Terminal-CR —
51. IPR-P_Ground_Drive2 —
52. IPR-P-Ground_Guide Paper —
53. PMO-Gear_Exit_DRV16 —
54. PMO-Bushing Feed —
55. Cover Open Actuator —
56. Paper Tray Empty Actuator 120N00425
57.
57-1.
57-2.
Feed Actuator
Spring-TS
PMO-Feed Actuator
009N01653
022N02127
58.
58-1.
58-2
Manual Feed Actuator
Spring-TS
PMO-Actuator Manual
120N00532
009N01657
709N00007
59.
59-1.
59-2.
59-3
Pick Up Gear Unit
Spring-CS
PMO-Gear Pick Up A
PMO-Gear Pick Up B
—
—
—
—
60. PMO-Locker CST —
61. PMO-Plate Guide Deve_L —
62. PMO-Plate Guide Deve_R —
66. MEC-Terminal —
67. Terminal-CRUM —
68.
68-1.
68-2.
68-3.
68-4.
68-5.
Clutch Assembly
Spring-TS
Gear-Feed 1
Shaft-Feed
PMO-Collar Spring
PMO-Hub Clutch
005N01031
—
—
—
—
—
73. Photo-Interrupter 130N01574
74. IPR-P-Terminal CON —
75. Bracket-Bush_TR L —
Parts List 6.0 Frame (Continued)
ID No. Name/Description Part Number
