Xerox Phaser 6180MFP - Main Components and Their Functions

Main Components and Their Functions
Phaser® 6180MFP Multifunction Printer
2-2
Main Components and Their Functions
This section includes:
■ Front View on page 2-2
■ Rear View on page 2-3
■ Internal View on page 2-4
■ Scanner on page 2-4
Front View
1. Front door A
2. Control panel
3. Output tray
4. Power switch
5. Button A for opening the front door
6. Tray 1 (MPT)
7. Tray 2
8. Optional Tray 3
6180mfp-002
1
3
2
5
4
6
7
8
