Xerox Phaser 6180MFP - Internal View; Scanner; Main Components and Their Functions

Main Components and Their Functions
Phaser® 6180MFP Multifunction Printer
2-4
Internal View
Scanner
1. Fuser
2. Print cartridge
3. Transfer unit
4. Button A for opening the front door
1. Duplex unit
1. Automatic document feed cover
2. Document guides
3. Document feed tray
4. Document glass
5. Scan bar lock switch
