Xerox Phaser 6600 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-15
Print Info Info Page Prints the printer configuration information on A4
paper.
2-33
Print Settings Prints the printer setting information on A4 paper. 2-34
Installation Serial No. Displays/specifies the serial number. 2-35
PagePack Displays the current PagePack status (Enable or
Disable).
HexDump Specifies whether to set HexDump to ON or OFF.
Tone Correction
(IOT tone correction)
Specifies whether to set IOT Tone Correction to ON or
OFF.
Pixel Counter Displays the last print pixel coverage (%) for 4 mm
square meter in A4 paper, per Y/M/C/K color.
Configuration Operates the DIP switches on the NVM in ESS.
XCPT Mode Displays/Specifies the XCPT Mode setting.
Print
Counter
Print Service Displays the current count of the Print Service.
Copy Service Displays the current count of the Copy Service.
FAX Service Displays the current count of the FAX Service.
Scan Service Displays the current count of the Scan Service.
Copy Counter M to B Copies the Master NVM values to the Backup NVM.
Copy Counter B to M Copies the Backup NVM values to the Master NVM.
Clear All NVM Initializes NVM.
Clear JobHistory Initializes the job data (log).
Clear AuditronPV Clears the AuditronPV data such as billing counter, user
account and user restriction settings.
Hard Drive Erase
(when the optional HD is
installed)
Deletes all data from the Hard Disk.
Clear DeviceData Deletes all data in the devices (EEPROM, SRAM, Fax
Memory, Hard Disk).
Printer Diag Function Names and Details
Function Description See

Xerox Phaser 6600 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Maximum duty cycle	80000 pages per month
Number of print cartridges	-
Internal memory	256 MB
Processor frequency	533 MHz
Maximum internal memory	768 MB
Sound pressure level (printing)	53 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	535 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Weight	25500 g
Dimensions (WxDxH)	429.26 x 487.68 x 383.54 mm
