Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-101
075 910 MSI Detached MSI Detached Bypass Tray
Missing
Error 075-910
Insert the Tray
Page 2-196
077 101 VSYNC ON JAM Detect VSYNC On JAM no message Replace the
MCU Board.
077 104 RegOff JAM Detect RegOff JAM no message Page 2-197
077 106 Exit ON JAM Detect Exit ON JAM no message Page 2-197
077 107 Duplex ON JAM Detect Duplex ON
JAM(TBD)
no message Page 2-198
077 108 ExitOff ealry JAM Detect ExitOff early JAM no message Page 2-198
077 109 ExitOff JAM Detect IOT Exit Sensor
Off JAM
no message Page 2-198
077 215 IOT Duplexer
Error
Duplexer Error
Power Off/On
Error 077-215
Power Off/On
-
077 217 Duplex Mis-
configuration
Duplex Mis-
configuration
Duplexer Error
Power Off/On
Error 077-217
Power Off/On
Replace the
MCU Board.
077 300 IOT Cover Front
Open
FrontCover Open.
Beep sounds after
FrontCover remains
open for 3 minutes.
Front Cover Open
Close FrontCover
Page 2-199
077 301 <IOT Side Cover
Open>
Side Cover is open. Side Door Open
Close Side Door
Page 2-199
077 304 IOT Cover Rear
Open
Rear Cover Open Rear Cover Open
Close Rear Cover
Page 2-200
077 312 Tray Configure
Error
Combination of trays
was illegal.
Tray Config Err.
Power Off/On
Error 077-312
Power Off/On
-
091 400 IOT Waste Toner
Box Near Life
Detect Waste Toner Box
Near Life
XXXXXXXXXXXXXXXX
Waste Toner Box
XXXXXXXXXXXXXXXX
Replace Soon
Page 2-200
Phaser 6600 Error Code List
Chain Link Error Error Details Control Panel Messages FIP location
