Error Troubleshooting
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
2-208
005-110 Pickup Jam
005-121 ADF Jam
005-124 Virtual Jam
4 Check after replacing the Black Imaging Unit
Replace the Black Imaging Unit.
Does the error still occur?
Replace the MCU
Board.
Finished.
Step Check Yes No
Possible causative parts:
• DADF Assembly (PL51.1.2)
• IIT Pick-up Module Kit (PL51.1.4)
• IP Board (PL18.1.22)
1 Check the document
Does the document meet the specifications of the printer?
Go to step 2. Use the right
document.
2 Check the DADF Assembly
Is the DADF Assembly closed properly against the platen
glass?
Go to step 3. Close the DADF
Assembly
properly.
3 Check the DADF Assembly connection
Check the connection between the DADF Assembly and the
IP Board.
Is P/J1502 connected securely?
Go to step 4. Connect P/J1502
securely.
4 Check the document path
Open the DADF cover and check the document path.
Are there any foreign objects, or paper pieces, etc. on the
document path?
Remove the
foreign objects,
or paper pieces,
etc.
Go to step 5.
5 Check the IIT Pick-up Module Kit
Is the IIT Pick-up Module Kit installed properly?
Go to step 3. Reinstall the IIT
Pick-up Module
Kit.
6 Check the IIT Pick-up Module Kit
Is the IIT Pick-up Module Kit deformed or worn out?
Replace the KIT
IIT Pick-up
Module.
Go to step 7.
7 Check after replacing the DADF Assembly
Replace the DADF Assembly.
Does the error still occur?
Replace the IP
Board.
Finished.
Step Check Yes No
To Next Page
